Garmin STRIKER™ Vivid 5cv with GT20-TM Transducer

SKU: $002000098051 ISBN: $002000098051

Product Code: GA010-02551-01

Price Includes VAT. 1 - 2 Working Days Standard Delivery £5.95 - UK Mainland.

£295.00 £340.00you save £45.00
Accepted Payment Methods:Supported payment methods
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Maestro
  • Mastercard
  • PayPal
  • Union Pay
  • Visa
Checking local availability

The Garmin STRIKER™ Vivid 5cv with GT20-TM Transducer is the perfect tool for any fisherman. With its advanced sonar capabilities and GT20-TM transducer, you'll get crystal clear images of fish and structure below the surface. Say goodbye to guesswork and hello to a more successful fishing experience.

In The Box

  • STRIKER Vivid 5cv
  • GT20-TM transducer
  • Power/data cable
  • Tilt/swivel mount
  • Hardware
  • Garmin bumper sticker
  • Documentation



The sonar colour you pick says a lot about your fishing style. Good thing there are 7 new vivid options.

What a view. Use the included transducer to get CHIRP traditional and ClearVü sonars.

Never lose a hot spot again. Use waypoint marking to find your way back.

What’s under the water’s surface looks pretty good as 1' contours, just saying.


CLEAR, COLOURFUL SONAR

Choose from 7 new vivid colour options to see fish and structure in maximum contrast and clarity on your 5″ fishfinder.

BUILT-IN SONAR

Use the included GT20 transducer to get Garmin CHIRP traditional sonar and CHIRP ClearVü scanning sonar.

WAYPOINT MARKING

To catch more fish, you need to know where the fish are biting. Use waypoint marking for hot spots so you can easily find your way back.

HIGH-SENSITIVITY GPS

Plan and create routes and view your boat’s speed on your fishfinder using high-sensitivity GPS.

QUICKDRAW CONTOURS

Nobody knows the waters you fish better than you. With the STRIKER Vivid 5cv fishfinder, you can store up to 2 million acres of maps with 1’ contours1.

INCLUDED HARDWARE

The STRIKER Vivid 5cv fishfinder includes a tilt/swivel mount plus transom and trolling motor mounting hardware and cable.

DIMENSION 7.4’’ x 4.5’’ x 2.1’’ (18.8 x 11.6 x 5.4 cm)
WEIGHT 1.0 lb (0.5 kg)
WATER RATING IPX7
DISPLAY TYPE WVGA colour
DISPLAY SIZE 2.6" x 4.3" (6.5 x 10.8 cm); 5.0" diag (12.8 cm)
DISPLAY RESOLUTION 800 x 480 pixels
MOUNTING OPTIONS flush, tilt/swivel
INPUT Keyed
Maps & Memory
WAYPOINTS/FAVOURITES/LOCATIONS 5000
TRACK POINTS 50,000
TRACKS 50
NAVIGATION ROUTES 100
Sensors
GPS Yes
HAS BUILT-IN RECEIVER Yes
SUPPORTS WAAS Yes
Optional Map Support
GARMIN QUICKDRAW CONTOURS Yes
Electrical Features
POWER INPUT 12 to 20 Vdc
TYPICAL CURRENT DRAW 0.40 A
MAX CURRENT DRAW 1.5 A
POWER CONSUMPTION

4.8

Sonar Features & Specifications
DISPLAYS SONAR Yes
TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) Built-in
CLEARVÜ Yes
FREQUENCY Traditional: 50/77/200 kHz CHIRP (mid and high) ClearVü: 260/455/800 kHz
TRANSMIT POWER 500 W (RMS)
BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) Yes
WATER TEMPERATURE LOG Yes
Connections
4-PIN TRANSDUCER PORTS 1
Fishfinder Features
SPLIT-SCREEN ZOOM Yes
FISH SYMBOL ID (HELPS IDENTIFY FISH TARGETS) Yes
AUTOGAIN TECHNOLOGY (MINIMISES CLUTTER, MAXIMISES TARGETS) Yes
ADJUSTABLE DEPTH LINE (MEASURES DEPTH OF UNDERWATER OBJECTS) Yes
A-SCOPE (REAL TIME DISPLAY OF FISH PASSING THROUGH TRANSDUCER BEAM) Yes
WATER TEMPERATURE SENSOR INCLUDED Yes
DEPTH RANGE SHADING Yes
Security Information
SECURITY UPDATES UNTIL AT LEAST (YYYY-MM-DD) 2022-10-27
Additional
ADDITIONAL
  • One 4-pin transducer port
  • Quickdraw Contours
  • Integrated GPS
  • Mark Waypoints
  • Course over Ground (COG)
  • Current draw @ 12V: 0.40A
