Em-Trak A200 Class A AIS Transceiver
Product Code: EMT425-0012
Price Includes VAT. 1 - 2 Working Days Standard Delivery £5.95 - UK Mainland.
EM-Trak A200 Class A AIS Transceiver
The EM-Trak A200 Class A AIS Transceiver is a cutting-edge solution designed to meet the highest standards of marine safety and navigation compliance. It delivers exceptional performance and reliability in the most demanding environments, catering to both SOLAS (Safety of Life at Sea) and EU Inland Waterway certifications for global maritime operations.
Key Features and Benefits:
Compliance and Certification
The A200 is fully certified to meet IMO SOLAS Class A and EU Inland Waterway standards, ensuring it is suitable for professional mariners operating across international waters and inland waterways. This universal compliance guarantees operational confidence in any maritime region.
Ruggedized Design
The A200 is engineered to withstand harsh environmental conditions. With water ingress protection rated to IPx6 and IPx7, it remains impervious to heavy rain, splashes, and immersion. Additionally, it is resistant to shock, vibration, and extreme temperatures, making it a robust choice for maritime environments.
Next-Generation GPS
The integrated high-performance GPS ensures unparalleled positioning accuracy and reliability, critical for safe navigation and effective AIS functionality.
Versatile Installation Options
The A200 can be installed internally or permanently mounted externally, providing flexibility for different vessel configurations and operational needs.
Ergonomic User Interface
Designed with user convenience in mind, the A200 features robust buttons and a rotary knob, making it easy to operate even in challenging conditions. Its configurable, multi-lingual menu ensures accessibility for users worldwide.
Integrated Colour Display with Night Mode
The high-definition colour display offers clear visibility in all lighting conditions. The night mode ensures a comfortable and glare-free experience during nighttime operations.
Enhanced Navigation Tools
With support for ENC charts (C-MAP), the A200 allows for configurable AIS target overlays directly on the chart, giving operators a comprehensive and intuitive view of the surrounding marine environment.
Silent Mode
For operations requiring discretion, Silent Mode disables AIS transmissions while continuing to receive all incoming messages, ensuring situational awareness without revealing the vessel's location.
Built-In WiFi
Integrated high-performance WiFi enhances connectivity and facilitates seamless data sharing with other onboard systems, mobile devices, or external networks.
Sophisticated AIS Functionality
The A200 includes advanced AIS features such as:
-
- Alerts and alarms for enhanced safety.
- Target filters to prioritize critical information.
- Comprehensive vessel information lists.
- Real-time weather data for improved situational awareness
Applications:
The EM-Trak A200 Class A AIS Transceiver is ideal for commercial vessels, fishing boats, passenger ships, and any maritime operations requiring robust and compliant AIS solutions. Its versatility, ease of use, and advanced features make it a trusted choice for maritime professionals worldwide.
Whether navigating the open seas or inland waterways, the A200 ensures safety, reliability, and efficiency, making it a valuable asset for modern maritime operations.
A200 Details
- IMO SOLAS Certified AIS Class A
- EU Inland Waterway Certified
- Ruggedized and impervious to extreme environments – water (IPx6 & IPx7), damp, shock, vibration, temperatures
- High performance next generation GPS
- Suitable internal or permanent external installation
- Robust ergonomic button and rotary-knob user interfaces with configurable multi-lingual menu options
- Integrated colour display with night mode
- ENC chart (C-MAP) with configurable AIS target overlay
- Silent mode – AIS transmissions are stopped – all messages continue to be received
- Integrated high performance WiFi
- Pilot plug cable and Junction Box accessory options
PHYSICAL AND ENVIRONMENTAL SPECIFICATION
Size (w x h x d) – 152 x 165 x 95mm
Weight – 1.1kg
Operating temperature – -25°C to +55°C
Storage temperature – -25°C to +70°C
Ingress protection – IPx6 and IPx7
ELECTRICAL SPECIFICATION
Supply voltage – 12V or 24V DC
Supply voltage range – 9.6V – 31.2V DC
Average current (at 12V) – 520mA
Peak current – 6A
Average power consumption (at 12V) – 6.2W
Galvanic isolation – NMEA 0183, NMEA 2000, Power supply, VHF antenna port
CONNECTORS
VHF antenna – SO-239
GNSS – TNC
Power – 2 way circular multipole
NMEA 0183/silent mode/blue sign – 14 way circular multipole
NMEA 0183/alarm relay – 18 way circular multipole
NMEA 2000 – 5 way Micro-C connector
DATA INTERFACES
NMEA 0183 – 3 x input ports. 3 x bi-directional ports
NMEA 2000 – NMEA 2000 Ed 3.101, LEN=1
Wi-Fi – IEEE 802.11 (a/b/g), client and access point mode supported (5 connections in access point mode)
STANDARDS COMPLIANCE
AIS standards – IEC 61993-2 Ed. 3
Product safety standards – EN60950-1 2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013
Environmental standards – IEC 60945 Ed. 4
Serial data interface standards – IEC 61162-1 Ed 5.0. IEC 61162-2 Ed 1.0
NMEA 2000 – NMEA 2000 Ed 3.101
GNSS performance standards – IEC 61108-1 Ed 2.0. IEC 61108-02 Ed 1.0
GNSS
Systems supported – GPS, GLONASS, BeiDou, Galileo
(two of any combination, three including GPS, Galileo)
Channels – 72
Internal/external antenna – External only
Time to first fix from cold start – 26s
VHF TRANSCEIVER
VDL access scheme – SOTDMA
Operating frequency – 156.025MHz – 162.025MHz
Channel bandwidth – 25kHz
Receivers/transmitters – 3 x receivers, 1 x transmitter
AIS receiver sensitivity (20% PER) – -111dBm
AIS transmitter power – 12W (+41dBm)
USER INTERFACE
Screen – 5″ 800 x 480 full colour LCD
Buttons – Rotary encoder for selection and entry, 4 menu keys and 4 direction keys
SD card interface – Micro SD card interface for logging and chart cards (not available from em-trak)
GNSS ANTENNA
Size – 85 x 70mm
Weight – 470g
Ingress protection – IPx6 and IPx7
Mounting – 1 inch 14 TPI pole mount required
GNSS systems supported – GPS, GLONASS, Galileo, BeiDou
- 1 x AIS Transceiver
- 1 x Mounting Bracket and Fixings Pack
- 1 x Product Manual and Document Pack
- 1 x Power Cable
- 1 x 14 Way Data Cable
- 1 x 18 Way Data Cable
- 1 x GPS Antenna
