Em Trak B200 AIS Class B Transceiver 5W SOTDMA

• Certified AIS Class B – 5W SOTDMA
• Ruggedized and impervious to extreme environments – water (IPx6, IPx7), damp, shock, vibration, temperatures
• High Performance latest generation GPS
• Internal battery back-up for up to 120hrs operation – charge is automatically maintained by primary vessel power and automatically switches to battery if lost
• WiFi & Bluetooth wireless connectivity
• NMEA0183 & NMEA2000
• Low power consumption
• Anti-tamper protection
• Enhanced RF screening to protect against electromagnetic interference
• Built-in power surge protection

PHYSICAL AND ENVIRONMENTAL SPECIFICATION
Size (w x h x d) – 170 x 140 x 69mm
Weight – 695g
Operating temperature – -25°C to +55°C
Storage temperature – -25°C to +70°C
Ingress protection – IPx6 and IPx7

ELECTRICAL SPECIFICATION
Supply voltage – 12V or 24V DC
Supply voltage range – 9.6V – 31.2V DC
Average current (at 12V) – 240mA (1.6A when battery charging)
Peak current – 3.85A
Average power consumption (at 12V) – 2.9W (19.2W when battery charging)
Galvanic isolation – NMEA 0183 inputs only, NMEA 2000, VHF antenna port
Battery Capacity – 4600mAh
Battery Type – 3.7V Li-Ion rechargeable
Battery life (default operating conditions) – 48 hours

CONNECTORS
VHF antenna – SO-239
GNSS – TNC
Power – 2 way circular multipole
NMEA 0183/silent mode – 12 way circular multipole
NMEA 2000 – 5 way Micro-C connector
USB – USB Micro-B

DATA INTERFACES
NMEA 0183 – 2 x bi-directional ports
NMEA 2000 – NMEA 2000 Ed 3.101, LEN=1
USB – PC virtual com port for NMEA 0183 data
Wi-Fi – IEEE 802.11 (a/b/g), client and access point mode supported (2 connections in access point mode)
Bluetooth – BT Classic 4.0, 7 concurrent connections

STANDARDS COMPLIANCE
AIS standards – IEC 62287-2 Ed. 2. ITU-R M.1371.5
Product safety standards – EN60950-1 2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013 EN62311:2008
Environmental standards – IEC 60945 Ed. 4
Serial data interface standards – IEC 61162-1 Ed 5.0. IEC 61162-2 Ed 1.0
NMEA 2000 – NMEA 2000 Ed 3.101
GNSS performance standards – IEC 61108-1 Ed 2.0. IEC 61108-02 Ed 1.0

GNSS
Systems supported – GPS, GLONASS, BeiDou, Galileo
(two of any combination, three including GPS, Galileo)
Channels – 72
Internal/external antenna – External only
Time to first fix from cold start – 26s

VHF TRANSCEIVER
VDL access scheme – SOTDMA
Operating frequency – 156.025MHz – 162.025MHz
Channel bandwidth – 25kHz
Receivers/transmitters – 2 x receivers, 1 x transmitter
AIS receiver sensitivity (20% PER) – -111dBm
AIS transmitter power – 5W (+37dBm)

USER INTERFACE
Buttons – Integrated silent mode
Indicators – Power, transmit timeout, error, silent mode

GNSS antenna
Size – 85 x 70mm
Weight – 470g
Ingress Protection – IPx6 and IPx7
Mounting – 1 inch 14 TPI pole mount required
GNSS systems supported – GPS, GLONASS, Galileo, BeiDou

• 1 x AIS Transceiver
• 1 x GPS antenna
• 1 x Power Cable (2m)
• 1 x USB Cable
• 1 x Anti-Tamper Bracket
• 2 x Anti-Tamper Locking Plates
• 1 x Fixing Pack
• 1 x Mounting Template
